Especificaciones Técnicas
| Código del Producto | Modelo | Temperatura más baja (℃) | Rango de temperatura (℃) | Capacidad (L) | Consumo(W) | Precisión de temperatura (℃) | Flujo de la bomba de circulación (L/min) | Fuente de alimentación | Elevación de la bomba (m) |
|---|---|---|---|---|---|---|---|---|---|
| B-01-01-02-021701 | BellBaCirLiqEnfrBajT-1005 | -10 | -10~RT | 5 | 350 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021702 | BellBaCirLiqEnfrBajT-1505 | -15 | -15~RT | 5 | 300 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021703 | BellBaCirLiqEnfrBajT-2005 | -20 | -20~RT | 5 | 180 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021704 | BellBaCirLiqEnfrBajT-3005 | -30 | -30~RT | 5 | 150 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021705 | BellBaCirLiqEnfrBajT-4005 | -40 | -40~RT | 5 | 200 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021706 | BellBaCirLiqEnfrBajT-1510 | -15 | -15~RT | 10 | 600 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021707 | BellBaCirLiqEnfrBajT-2010 | -20 | -20~RT | 10 | 1150 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021708 | BellBaCirLiqEnfrBajT-3010 | -30 | -30~RT | 10 | 300 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021709 | BellBaCirLiqEnfrBajT-4010 | -40 | -40~RT | 10 | 400 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021710 | BellBaCirLiqEnfrBajT-1015 | -10 | -10~RT | 15 | 800 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021711 | BellBaCirLiqEnfrBajT-3015 | -10 | -10~RT | 15 | 700 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021712 | BellBaCirLiqEnfrBajT-1020 | -10 | -10~RT | 20 | 1000 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021713 | BellBaCirLiqEnfrBajT-2020 | -20 | -20~RT | 20 | 1000 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021714 | BellBaCirLiqEnfrBajT-3020 | -30 | -30~RT | 20 | 1300 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021715 | BellBaCirLiqEnfrBajT-4020 | -40 | -40~RT | 20 | 1400 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021716 | BellBaCirLiqEnfrBajT-1030 | -10 | -10 ~RT | 30 | 800 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021717 | BellBaCirLiqEnfrBajT-2030 | -20 | -20~RT | 30 | 2300 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021718 | BellBaCirLiqEnfrBajT-3030 | -30 | -30~RT | 30 | 1500 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021719 | BellBaCirLiqEnfrBajT-4030 | -40 | -40~RT | 30 | 1000 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021720 | BellBaCirLiqEnfrBajT-1050 | -10 | -10~RT | 50 | 1000 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021721 | BellBaCirLiqEnfrBajT-2050 | -20 | -20~RT | 50 | 2500 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021722 | BellBaCirLiqEnfrBajT-3050 | -30 | -30~RT | 50 | 4000 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
| B-01-01-02-021723 | BellBaCirLiqEnfrBajT-3080 | -30 | -30~RT | 80 | 2800 | ±0.5 | 15 | 220V±10%, 50/60Hz | 4 |
