| Tipo de calentamiento | Water-jacket/Air-jacket | Water-jacket/Air-jacket | Water-jacket/Air-jacket |
| Tipo de control de CO2 | Gas proportion type | Gas proportion type | Gas proportion type |
| Funcion de alarma | Over-temperature alarm, temperature sensor error alarm, water-shortage alarm | Over-temperature alarm, temperature sensor error alarm, water-shortage alarm | Over-temperature alarm, temperature sensor error alarm, water-shortage alarm |
| Rango de temperatura | RT+3 ℃ -60 ℃ (Room temperature:5 ℃ -35 ℃ ) | RT+3 ℃ -60 ℃ (Room temperature:5 ℃ -35 ℃ ) | RT+3 ℃ -60 ℃ (Room temperature:5 ℃ -35 ℃ ) |
| Tipo de control de temperatura | PID | PID | PID |
| Conveccion de la sala de trabajo | Small flow forced convection | Small flow forced convection | Small flow forced convection |
| Fluctuacion de temperatura | ≤±0.2 ℃ | ≤±0.2 ℃ | ≤±0.2 ℃ |
| Uniformidad de temperatura | ≤±0.3 ℃ | ≤±0.3 ℃ | ≤±0.3 ℃ |
| Rango de temporizacion | Continuous working or 1-9999min | Continuous working or 1-9999min | Continuous working or 1-9999min |
| Tipo de humidificacion | Water plate natural evaporation | Water plate natural evaporation | Water plate natural evaporation |
| Tipo de desinfeccion | UV light | UV light | UV light |
| Dimension del contorno (cm) | 57*59*93 | 67*64*111 | 77*79*108 |
| Dimension de la camara (cm) | 41*40.5*51 | 50.5*45.5*70 | 60*60*75 |
| Sala de trabajo (L) | 80 | 160 | 270 |
| P.N./P.B. | 60/90 | 80/115 | 132/165 |
| Potencia nominal (W) | 600(air jacket) 600(water jacket) | 700(air jacket) 900(water jacket) | 1200(air jacket) 2100(water jacket) |
| Estantes (configuracion estandar) | 2 | 3 | 3 |
| Material | Outer shell and door: Cold-rolled plate coated; internal working chamber: Stainless steel; inner door: Tempered glass; heat insulation: Centrifugal glass fiber | Outer shell and door: Cold-rolled plate coated; internal working chamber: Stainless steel; inner door: Tempered glass; heat insulation: Centrifugal glass fiber | Outer shell and door: Cold-rolled plate coated; internal working chamber: Stainless steel; inner door: Tempered glass; heat insulation: Centrifugal glass fiber |
| Condicion de prueba | The parameters are tested under zero load operation with the room temperature 20 ℃ and the ambient humidity 50% RH. Not for long time cold storage. | The parameters are tested under zero load operation with the room temperature 20 ℃ and the ambient humidity 50% RH. Not for long time cold storage. | The parameters are tested under zero load operation with the room temperature 20 ℃ and the ambient humidity 50% RH. Not for long time cold storage. |
